Application of Intelligent Lighting System in Sino-US Shanghai Shiguibao Biopharmaceutical Co., Ltd.

An Kerui Cui Tingyu

Jiangsu Ankerui Electric Appliance Manufacturing Co., Ltd.

Abstract: With the development of social economy and the improvement of network technology and communication technology, people have put forward new requirements for lighting design. It not only controls the lighting time and brightness of the lighting source, but also cooperates with other systems for different applications. The corresponding lighting scene. As the application structure of social resources continues to change, the application of intelligent lighting control systems has become a new trend in the development of power resource applications. This article describes the application of smart lighting in the factory through the application of lighting in the Sino-US Shanghai Shi Guibao Biopharmaceutical Co., Ltd. project.

Key words: intelligent lighting system; energy saving and emission reduction; lighting control;

0 Preface

With the continuous development of science and technology, human society has ushered in the era of electronic information. Intelligent lighting control technology, with the rapid development of intelligent residential development, has become an important direction in the development of lighting control technology. Therefore, according to the advantages and disadvantages of the existing intelligent lighting control system, the lighting control law is determined according to the people's behavior pattern and the light environment of the house, and the intelligent lighting control system is very effective in improving people's life quality, saving energy, and advocating green lighting. Significance.

1 Project Overview and Construction Objectives

Smart lighting systems are used in many places, not only in homes, corporate offices, but also in many factories using smart lighting systems. With the advancement of social modernization, our country’s factories are constantly under construction. With the need for lighting technology is also constantly improving, lighting problems also reflect the technical achievements of a total of projects, a good intelligent lighting system can give a factory a good The built environment makes people feel very comfortable in the factory area. The unfavorable loss caused to the project by the unfavorable intelligent lighting system is very large. It will not only result in the failure of quality, but may even cause the consequences of re-construction. Therefore, the application of intelligent lighting systems in buildings should be feasible, quality clearance, practical and reliable.

2 Smart Lighting Design

A building uses an intelligent lighting system that can be set in advance with a light level and exposure range. After the setting is completed, the building's lighting system is completely in full smart state, and the entire day's lighting equipment will be in a smart work state. When daytime, the intelligent lighting system automatically adjusts the indoor lighting level according to the outdoor light level. When the night is dark, the smart lighting system will be adjusted to work brighter than the daytime. Brightness. The intelligent lighting system adjusts the indoor lighting brightness according to different indoor brightness, helping people in the interior to better experience an all-intelligent photometric adjustment environment, making people's living and working environment become very natural and appropriate.

1.1 Practicality of Intelligent Lighting System

In addition to the ability to automatically adjust the light, the smart lighting system can also change different working modes according to people's settings, improve people's working status and improve work efficiency. Working in the original lighting system, people often work for a long time, they will feel tired eyes, body aches, swollen brains and other unpleasant phenomena, and even seriously affect the progress of work, because inappropriate lighting will bring a lot of The emergence of such problems. However, the intelligent lighting system now solves these problems. The comfortable intelligent lighting system strictly controls the lighting brightness and long-lasting light in the working environment, so that the people's body is relaxed under the working conditions, and brings people to work. A very comfortable working environment, but also improve people's work efficiency.

1.2 Smart Lighting System Cost Savings

The old-fashioned lighting system not only caused people physical discomfort, but also caused people's huge lighting costs and management costs. The modern intelligent lighting system can help people to solve the physical discomfort, and at the same time, it also solves the problem of cost in the old lighting system. The current intelligent lighting system is very energy-efficient. Because the working mode of the lighting system is intelligent, it adjusts the brightness of the interior according to the brightness level. This effectively avoids the lighting caused by the bright outdoor lighting and the bright interior. Waste, but also based on unnecessary lighting, and automatically turn off the lighting system to save costs.

2.1 System Structure Based on the distribution of lighting status of Sino-US Shanghai Shiguibao Biopharmaceutical Co., Ltd., the system includes: station management layer and field device layer. The network structure of the system is shown in the figure:

The field device layer is mainly connected to the switching power supply, driver, and human inductive Sensor in the network, and is also a necessary basic element for constructing the lighting system.

2.2 Network Design The network system in the intelligent lighting monitoring system can transmit data in time and quickly transfer operation instructions, which is the basis for realizing various functions of the intelligent lighting system. Connect each device on-site with the bus in the field, and then connect all busses to the control panel to achieve lighting control through the control panel.

2.3 monitoring system software function design

2.3.1 Timing and Scene Control

Intelligent lighting system through the clock manager, to achieve the entire system of regional lighting timing and automatic management functions, to achieve common channel timing control. Such as holiday lighting timing off, regular notice and so on.

The intelligent lighting control system sets different types of scene modes according to the needs of various departments, performs various combinations of lighting and lighting, and achieves the effect of beautifying the working environment. In combination with human body sensors, when the personnel leave, all lighting is turned off.

2.3.2 Human body induction control and constant illumination control

The intelligent lighting system can arrange human body sensors in office walkways and stairs. When someone enters the area, the lighting is turned on automatically. When the person leaves, delay it for a period of time before closing it. If someone enters within the delay time, it will re-enter the open mode to save energy. And can be set to be effective during the day, invalid at night, according to demand settings. In the indoor office area, the illuminance sensor is arranged to automatically adjust the brightness and number of lights of the indoor lighting according to the external natural light source. It not only makes full use of the natural light, but also creates a comfortable working environment for the indoor personnel.

3 The significance of smart lighting system

In summary, the development of modernization has led to the realization of intelligent lighting. More and more factories have already used smart lighting systems. Intelligent lighting systems not only give people different experiences in function, but are more suitable for people's work. use. Modern factories mostly use smart lighting systems. Compared to old-fashioned lighting methods, modern intelligent lighting systems are more popular; smart lighting systems save energy in factories, save costs through effective management, and effectively benefit natural light sources and lighting systems. Resource sharing and other ways to achieve resource savings. There are many advantages and practicalities of the intelligent lighting system. At the same time, the intelligent lighting system is constantly developing and improving. In the future, the factory will use the intelligent lighting system to control the lighting.

references

[1] Panlong intelligent lighting system energy-saving analysis and design [J] Building Energy Efficiency 2011

[2] Zhang Xibin Talking about Building Energy Saving Technology Measures [J] Science and Technology Innovation Guide 2011
