Asphalt wax content tester

MTSL-25

Asphalt wax content tester

main feature:

The petroleum asphalt wax content measuring instrument is an automatic method developed by our factory according to the “Standard Method for Analysis of Wax Content of Petroleum Bitumen” issued by China Petrochemical Industry Corporation, SH/TO425 “Experimental Method for Wax Content of Bitumen” (Distillation Method). Special instrument for constant temperature and refrigeration petroleum asphalt content. This instrument complies with the JTG E52-2011 standard of the Ministry of Communications.

The temperature control part adopts digital electronic temperature control table chiller with high precision, fast reflection and clear reading. It is imported 15KW, F22 high power compressor, and deep cold can reach -28 °C. It solves the shortcomings of the previous use of artificial dry ice cooling, temperature caused by Dewar insulation is not easy to control, can only do one sample at a time, and difficult to analyze and test.

The petroleum asphalt wax measuring instrument can perform analysis test of three samples at a time. It has the advantages of rapid cooling, high control precision, easy operation, time saving and so on. It is an ideal analytical instrument for petroleum, chemical, construction, highway construction and other industries.

Asphalt wax content tester

Purpose and scope of application

The method is suitable for determining the wax content of road petroleum asphalt by pyrolysis distillation.

Asphalt wax content tester

Instruments and materials

Distillation flask: made of heat-resistant glass.

Cooling filter: Select the cooling filter according to the conditions.

A cooling filter device consisting of a sand core filter funnel, a suction filter bottle, a sample cooling cylinder, a plug and a cold bath, and a filter funnel (P16) having a pore size coefficient of 10 μm to 16 μm.

A cooling filter consisting of a glass funnel (G3 or G4), a glass jacket, a suction filter bottle, a rubber gasket, and the like. The connection is made of glass ground plugs, and the outer jacket of the glass jacket is insulated.

Vertical high temperature electric furnace: vertical, 950 °C.

Balance: The sensitivity is not more than 1mg and not more than 0.1g each.

Thermometer: -50 ° C ~ +60 ° C, the index is 0.5 ° C.

Erlenmeyer flask: 150 mL or 250 mL several.

Glass funnel: 40 mm in diameter.

Water pump or vacuum pump.

An anhydrous ethanol mixture: analytically pure, prepared in a volume ratio of 1:1.

The oil is dehydrated by silica gel (60 ° C ~ 90 ° C): analytically pure.

Industrial alcohol and dry ice hydrocarbons (solid CO2).

Low temperature water tank: -30 ° C ~ +60 ° C, the coolant medium can be used methanol or ethylene glycol aqueous solution.

Ice cubes.

Others: electric heating sleeve, gas furnace, oven, constant temperature water tank, measuring cylinder, beaker, iron frame, U-shaped mercury column pressure gauge (or vacuum gauge), washing liquid, distilled water, thermometer, electric furnace, etc.

Asphalt wax content tester

The main technical parameters:

Machine power: 2.5KW. (Cooling power: 1.5KW, heating power: 1KW).

Stirring motor speed: 1400 rpm.

The refrigerant is F22 and the limit temperature is -30 °C.

Conditions of use: power supply voltage 220V, frequency 50HZ, ambient temperature: room temperature, relative humidity less than 85%.

Dimensions: 780 × 650 × 1300mm (cooling).

Temperature control accuracy: ±0.5 °C.

Weight: 118KG

Ambient temperature: 5 ~ 40 ° C

Ambient humidity: ≦ 85%

Asphalt wax content tester display chart:
